| MODEL |
DIMENSIONS (m/m) |
MATERIALS |
표면처리(FINSH) |
허용하중(4EA/kg) |
| D |
M |
S |
H |
N |
B |
LD |
P |
BOLT & NUT |
하부 |
ARB
NARB
(STEEL)
SARB
PSARB
(SUS) |
46 |
M6X1.0 |
40 |
62 |
6 |
16 |
62.5 |
26.5 |
SM10C
SUS304 |
2.6t(SPHC)
2.5t(SUS304) |
ARB
아연백색(Zn)
NARB
니켈(Ni)
SARB
일반(Natural)
PSARB
포리싱(PL) |
100 |
| M8X1.25 |
40 |
62 |
200 |
| 80 |
102 |
| M10X1.5 |
60 |
83 |
7 |
300 |
| 100 |
123 |
| 68 |
M12X1.75 |
50 |
78 |
8 |
20 |
89.3 |
39 |
3t(SPHC)
3t(SUS304) |
600 |
| 75 |
103 |
| 100 |
128 |
| 125 |
153 |
| 150 |
178 |
| 200 |
228 |
| 81 |
M16X2.0 |
50 |
83 |
10 |
23 |
118 |
58 |
800 |
| 75 |
108 |
| 100 |
133 |
| 130 |
163 |
| 150 |
183 |
| 180 |
213 |
| 200 |
233 |
| 250 |
283 |
| 300 |
333 |
13 |
| M20X2.5 |
80 |
116 |
1000 |
| 100 |
136 |
| 130 |
166 |
| 150 |
186 |
| 180 |
216 |
| 200 |
236 |
| 250 |
286 |
| 300 |
336 |
| 103 |
M20X2.5 |
80 |
121 |
13 |
28 |
138 |
67 |
4.5t(SPHC)
4.0t(SUS304) |
1500 |
| 100 |
141 |
| 130 |
171 |
| 150 |
191 |
| 180 |
221 |
| 200 |
241 |
| 250 |
291 |
| 300 |
341 |
| M24X3.0 |
100 |
144 |
2200 |
| 150 |
194 |
| 200 |
244 |
| 250 |
294 |
|
